1. Thickness: 8mm-700mm
2. Length: 3000mm-27000mm or as required
3. Width: 1500mm-4020mm
4. Application: Pressure vessel steel plate, Boiler steel plate
5. Additional Processing Options: Hot rolled, controlled rolling, normalizing, annealed tempering, normalizing+ tempering, hardening + tempering, HIC, SSC, SPWHT, Third Party Test.
6. Surface Finish: Coated or Shot Blasting and Painting.
7. Delivery Condition: Hot Rolled, Cold Rolled
8. Steel Grades: 15Mo3, 13CrMo4-4, 17Mn4, 10CrMo9-10, 19Mn6, HII, HI

CG Steel provides Din17155 steel plate and equivalent grades to meet customer needs. The DIN 17155 standard, a former German specification for gas cylinders, gas vessels, and pressure vessel plates, has been outdated. This specification, in conjunction with the BS standard, has been succeeded by EN 10028. Given its historical significance and continued demand, CG Steel is equipped to manufacture steel plates and sheets in accordance with this specification.

DIN17155 HII stands out as a widely favored steel grade for gas cylinder manufacturing, offering excellent welding performance. Welding is carried out in compliance with pressure requirements. Other grades such as HI, 17Mn4, etc., can be substituted with various alternative standards.

DIN 17155 Chemical Composition:

Steel Grade	C	Si	Mn	P	S	Al	Cr	Cu	Ni	Mo	Nb	Ti	V
15Mo3	0.12-0.20	0.10-0.35	0.40-0.90	0.035	0.030		0.25	0.3	0.3	0.25-0.35
13CrMo4 4	0.08-0.18	0.10-0.35	0.40-0.10	0.035	0.030		0.70-1.10	0.3		0.4-0.6
17Mn4	0.14-0.20	0.40	0.90-1.40	0.035	0.030	0.02	0.25	0.3	0.3	0.10	0.01	0.03	0.03
10CrMo9-10	0.06-0.15	0.50	0.40-0.70	0.035	0.030		2.00-2.50	0.3		0.9-1.0
19Mn6	0.20	0.50	0.90-1.70	0.030	0.025	0.02	0.30	0.3	0.3	0.08	0.05	0.03	0.10
HI	0.16	0.35	0.40/1.20	0.03	0.025	0.02	0.3	0.3	0.3	0.08	0.01	0.03	0.02
HII	0.20	0.35	0.50-1.30	0.035	0.030	0.02	0.25	0.3	0.3	0.10	0.01	0.03	0.03
Ast 41	0.20	0.35	0.45	0.045	0.045		0.3

DIN 17155 Mechanical Property

Steel Grade	15Mo3 Mechanical Property
	Thickness	Yield
15Mo3	mm	Min Mpa
	6-16	275
	16-40	270
	40-60	260
	60-100	240
	100-150	220
13CrMo4-4	6-16	300
	16-40	295
	40-60	295
	60-100	275
	100-150	255
17Mn4	6-16	290
	16-40	285
	40-60	280
	60-100	255
	100-150	230
10CrMo9-10	6-16	310
	16-40	300
	40-60	290
	60-100	270
	100-150	250
19Mn6	6-16	355
	16-40	355
	40-60	355
	60-100	355
	100-150	355
HII	6-16	265
	16-40	255
	40-60	245
	60-100	215
	100-150	200
HI	6-40	Yield Min 235
		Tensile 360-480
	40-100	Yield Min 235
		Tensile 360-480

DIN 17155 Equivalent Steel Grade:

DIN 17155	Material #	EN 10028-2	NFA 36-205	UNI 5869	BS 1501	UNE 36087	ASTM	JIS G3115
HI	1.0345	P235GH	A 37 CP	Fe 360 - 1KW	161 Gr. 360 / 164 Gr. 360	A 37 RCI	A 285 Gr. C-A 414 Gr. C / A 516 Gr. 55	SPV 24
HII	1.0425	P265GH	A 42 CP	Fe 410 - 1KW	161 Gr. 400 / 164 Gr. 400 / 224 Gr. 400	A 42 RCI	A 414 Gr. E / A 516 Gr. 60
17 Mn 4	1.0481	P295GH	A 48 CP	Fe 460 - 1KW	224 Gr. 490	A 47 RCI	A 414 Gr. F / A 516 Gr. 65	SPV 32
19 Mn 6	1.0473	P355GH	A 52 CP	Fe 510 - 1KW		A 52 RCI	A 414 Gr. G	SPV 36
15 Mo 3	1.5415	16Mo3	15 D3	15 Mo 3	1503 - 243 B	16 Mo 3	A 204 Gr. B
13CrMo 4 4	1.7335	13CrMo4-5	15 CD 4-05	14 CrMo 4.5	620 Gr. 27	14 CrMo 4.5	A 387 Gr. 12
10CrMo 9 10	1.738	10CrMo9-10	10 CD 9.10		622 Gr. 31		A 387 Gr. 22
